CBT: CONFIDENCE BRAKE TECHNOLOGY

At FFWD Wheels we are constantly working on improvement of our products. In this process of product deve- lopment we learned that the combination of compounds will make the difference between good or great. As techniques develop quickly it remains a continuous process at FFWD Wheels!

FFWD Wheels applies three different brake track layers depending on the type of rim or type of use.

CBT BBS
All FFWD tubular (road) rims have a Basalt brake surface (BBS). Reducing heat production and improving brake performance in combination with the supplied SwissStop black prince brake pads.

CBT 1.5
Based on 1.5k CARBON structure in combination with High TG Custom Compound Resin. Increasing braking power by 30% in all conditions, more durable and doesn’t make noise while braking.

CBT 3H
The F3R FCC has an exclusive brake surface. Mixing three different composites and a copper layer with a High TG Resin enables fast heat reduction and high brake efficiency. Durable and capable of higher tire pressure.

DARC

FFWD DARCTM technology is short for ‘Double Arc’ which refers to the profile of the rim. The revolutionary DARCTM profile improves aerodynamics dramatically by reducing the drag. Air has the characteristic to stick to its surface and by cre¬ating a negative arc section the air will be compressed more at the positive section. This will increase the pressure just like on the topside of an airfoil. Increased pressure results in a faster airflow and less resistance on the wheel which reduces the drag. The DARCTM profile is applied to all F4R, F6R and F9R models


Carbon

We use High-Tensile TC-35 carbon for the majority of the lay-up. This gives the rim a very high strength with sufficient stiffness to cope with hard application of the wheels. So, rather than use a stiffer, but more brittle carbon type, we chose durability over ultimate stiffness. In some lay-ups we add some higher modulus sheets to increase stiffness locally.

We actually use multiple layers of different types of carbon. Only the outer layer is made from a 3K weave. Underneath this layer are layers of UDF (Uni-Directional Fiber) sheets. A mixture of different angles to resemble a uniform material. Because carbon fiber can handle tension very well, we have to mix up the layers to make the rim stiff and strong enough. Pressure is not a great feature of a fiber. Just think of a string being pushed [1]). But when mixed correctly, the different angles interconnect through the resin to make it resistant to all kinds of forces [2].
The 3K has a slightly lower stiffness/weight ratio than UDF (Uni-Directional Fiber) sheets of equal fibers, but it makes up by giving the rims a bombproof feature. Why? Because when a strand (or multiple) gets cut in UDF, by crashing for instance, the sheet is compromised and the tear will expand through a larger part of the sheet at continuous workload. A weave will stop the tear because it is intervened by the crossing layer of strands [3].

Although it is not advised to ride with a ‘hole’ in your rims, situations can occur where you might not know of a damaged rim or it is not an option to stop right away. Then you have the extra safety of the 3K weave to get you home.
